| Attribute | Value |
|---|---|
| Product Category: | |
| Manufacturer: | Amphenol Sine Systems |
| Manufacturer Part Number: | Amphenol Sine Systems AG6FL |
| Series: | AG |
| Connector Type: | XLR |
| Gender: | Female |
| Housing Material: | Bronze, Zinc |
| Number of Contacts: | 6 |
| Mount Type: | PCB Mount |
| Termination Method: | Solder |
| Contact Material: | Brass |
| Contact Plating: | Gold Over Silver |
| Maximum Operating Temperature: | 80 °C |
| Minimum Operating Temperature: | -30 °C |
| IP Rating: | IP00 |
| Housing Color: | Nickel |
| Mating Cycles: | 2000 cycle |
| Wire Size: | 28 AWG - 0.38 mm² |
| Flammability Rating: | UL 94V-HB |
| Current Rating: | 1.2 A |
| SKU: | AMEAG6FL |
AG6FL
| Heilind Number: | AMEAG6FL |
| Manufacturer: | Amphenol Sine Systems |
| Manufacturer Number: | AG6FL |
| ECAD Model: | |
Description:
AG6FL 6 Pole Mini XLR Cable Connector, G Type, Female, Stamped Contacts, Nickel Finish
More >>Specifications
Detailed Description
The AG6FL 6 Pole Mini XLR Cable Connector is a high-performance audio connector designed for professional use. Featuring a G Type female configuration with stamped contacts, this connector ensures secure and reliable signal transmission. Its durable zinc and bronze housing, along with a nickel finish, guarantee longevity and stability in any application. With a maximum operating temperature of 80 °C and a minimum of -30 °C, it performs flawlessly even in demanding environments. The connector is PCB mountable, with a solder termination method, making installation easy and efficient. Gold over silver contact plating ensures optimal conductivity, while a current rating of 1.2 A accommodates high-performance audio systems. Rated at 2000 mating cycles and with a flammability rating of UL 94V-HB, this connector is both reliable and safe. Perfect for audio, video, and broadcast applications, the AG6FL is a essential component for professionals in the industry.
