| Attribute | Value |
|---|---|
| Product Category: | |
| Manufacturer: | Amphenol Sine Systems |
| Manufacturer Part Number: | Amphenol Sine Systems C091 31D003 101 2 |
| Color: | Nickel |
| Gender: | Female |
| Shielded: | Yes |
| IP Rating: | IP69K |
| Wire Size: | 20 AWG |
| Mount Type: | Cable Mount |
| Shell Size: | M16 |
| Mating Type: | Screw |
| Mount Angle: | Straight |
| Mating Cycles: | 500 cycle |
| Current Rating: | 10 A |
| Voltage Rating: | 250 V, 300 V |
| Contact Plating: | Silver |
| Housing Material: | Die-Cast Zinc |
| Number of Contacts: | 3 |
| Termination Method: | Solder |
| Maximum Operating Temperature: | 100 °C |
| Minimum Operating Temperature: | -40 °C |
| SKU: | AMEC091 31D003 101 2 |
C091 31D003 101 2
Specifications
Detailed Description
Introducing the C091 31D003 101 2 FEMALE CABLE CONNECTOR 3W in sleek Nickel finish. Designed for seamless connectivity, this Female connector boasts a sturdy Die Cast Zinc housing and features 3 contacts with Silver plating, ensuring reliable performance. Suitable for Cable Mount installation with straight mount angle, it guarantees a secure fit. With an IP69K rating for high ingress protection, it can withstand demanding environments. The M16 shell size, Screw mating type, and shielded design further enhance its versatility. RoHS compliant, it meets environmental standards. With a wire size of 20 AWG and a current rating of 10A at 250V/300V, this connector is ideal for various applications in the Circular DIN Connectors category. Experience durability and efficiency with the C091 31D003 101 2.
Availability
In Stock:
Call
Stock Location:
In Stock
Factory Stock:
Call for Stock
Factory Lead:
Call
Unit Of Measure:
Each
Minimum/Multiple:
1/1
Invalid quantity value
Environmental & Export Classifications
| Attribute | Value |
|---|---|
| RoHS Compliant: | Unkown |
