| Attribute | Value |
|---|---|
| Product Category: | |
| Manufacturer: | Amphenol Sine Systems |
| Manufacturer Part Number: | Amphenol Sine Systems T 3637 404 |
| Series: | C091 M16-A |
| Gender: | Male |
| Housing Material: | Zinc Die Cast |
| Number of Contacts: | 12 |
| Mount Type: | Panel Mount |
| Termination Method: | Solder |
| Contact Plating: | Gold |
| Maximum Operating Temperature: | 100 °C |
| Minimum Operating Temperature: | -40 °C |
| IP Rating: | IP40 |
| Mating Type: | Screw |
| Mount Angle: | Straight |
| Mating Cycles: | 1000 cycle |
| Shielded: | Yes |
| Wire Size: | 24 AWG |
| Current Rating: | 3 A |
| Voltage Rating: | 150 V |
| SKU: | AMET 3637 404 |
T 3637 404
Specifications
Detailed Description
Introducing the T 3637 404, a rugged Rear Mounting Male Receptacle from the C091 M16-A series. Engineered for durability, this connector features a housing made of Zinc Die Cast, suitable for demanding industrial environments. With 12 gold-plated contacts, it ensures reliable signal transmission even in harsh conditions, operating smoothly between -40°C to 100°C. IP40 rated for dust protection, it guarantees secure connectivity. The Panel Mount design with solder termination method offers easy installation. With a straight mount angle and screw mating type, it provides a secure and stable connection. Shielded for added protection, it accommodates 24 AWG wire size, supporting a current rating of 3A and voltage rating of 150V. Ideal for Circular DIN applications, this connector is built for performance and longevity, with a mating cycle of 1000. Trust in the T 3637 404 for your connectivity needs.
