2178299-1

AMP2178299-1
Heilind Number:AMP2178299-1
Manufacturer:TE Connectivity
Manufacturer Number:2178299-1
Datasheet:Datasheet
ECAD Model:
3D Model

Description:

6.3 SRS F-SPRING LIF RECEPTACLE

More >>

Specifications

AttributeValue
Product Category:
Crimp Terminals, Housings, Splices, & Lugs Crimp Terminals, Housings, & Splices
Manufacturer:TE Connectivity
Manufacturer Part Number:TE Connectivity 2178299-1
Series:FASTON 250
Contact Material:Steel
Contact Plating:Pre-Nickel
Overall Length:19 mm, .748 in
Material:Steel
Compatible Tab Width:.25 in, 6.35 mm
Compatible Tab Thickness:.032 in, .81 mm
Terminal Type:Receptacle
Orientation:Straight
Operating Temperature Range:-40 - 250 °C, -40 - 482 °F
Wire Size:18 - 20 AWG, .51 - .82 mm²
Crimp Type:F-Crimp
Barrel Type:Open
Accepts Wire Insulation Diameter:.071 - .098 in, 1.8 - 2.5 mm
Product:Quick Disconnects
Product Type:Receptacle
SKU:AMP2178299-1

Detailed Description

Enhance your electrical connections with the FASTON 250 series Receptacle. Crafted from durable steel with a Pre-Nickel plating, this terminal ensures reliable performance in a range of environments, with an operating temperature range of -40 to 250°C (-40 to 482°F). Its straight orientation and F-Crimp design accommodate 18-20 AWG wire sizes, making it ideal for various applications. Featuring an open barrel for easy installation, it accepts wire insulation diameters from .071 to .098 inches (1.8 to 2.5 mm). Trust in this RoHS-compliant product for efficient and compliant wire termination in your projects.
