292491-1

AMP292491-1
Heilind Number:AMP292491-1
Manufacturer:TE Connectivity
Manufacturer Number:292491-1
Datasheet:Datasheet
ECAD Model:
3D Model

Description:

MBXL RCPT PMT 5P+24S+1RF+5ACP

More >>

Specifications

AttributeValue
Product Category:
Connectors Power Connectors
Manufacturer:TE Connectivity
Manufacturer Part Number:TE Connectivity 292491-1
Housing Material:Thermoplastic
Mount Type:Cable Mount (Free-Hanging)
Termination Method:Crimp
Pitch:.1 in, 2.54 mm, .3 in, 7.62 mm
Voltage:300 V AC, 300 V DC, 60 V AC, 60 V DC
Contact Type:Socket
Number of Positions:35
Housing Color:Black
GPL:E79
Packaging:Box
Operating Temperature Range:-20 - 105 °C, -4 - 221 °F
Circuit Application:Power & Signal
Sealable:No
GPL Description:Data and Devices
Connector and Contact Terminate To:Printed Circuit Board
Product Code:H091
Connector System:Cable-to-Board
Connector Product Type:Housing
ECCN:EAR99
Contact Retention:Without
Glow Wire Rating:Standard Part - Not Glow Wire
Connector and Housing Type:Receptacle
Material Flammability Standard:UL 94V-0
Part Aliases:292491-1
SKU:AMP292491-1

Detailed Description

Easily connect power and signals with this robust housing, designed for secure cable-to-board mounting. Featuring a durable thermoplastic construction in sleek black, it ensures reliable performance even in demanding environments. With 35 positions for sockets and crimp termination, it offers versatile connectivity for various applications. UL 94V-0 rated for safety, and compliant with RoHS standards, this housing guarantees peace of mind in terms of quality and environmental responsibility. Suitable for use in a wide temperature range from -20 to 105°C (-4 to 221°F), it's perfect for diverse industrial settings. Whether for data or device connections, this housing, part of the MBXL RCPT series, is a dependable choice for your connectivity needs. Packaged in a convenient box, it's ready for easy installation and use.
