| Attribute | Value |
|---|---|
| Product Category: | |
| Manufacturer: | HARTING |
| Manufacturer Part Number: | HARTING 09185605923 |
| Color: | Gray |
| Pitch: | 2.54 mm |
| Series: | SEK Standard |
| IP Rating: | IP20 |
| Mount Angle: | Right Angle |
| Tail Length: | 2.9 mm |
| Current Rating: | 1 A |
| Number of Rows: | 2 |
| Voltage Rating: | 1 kV |
| Contact Plating: | Noble Metal Over Nickel, Tin Over Nickel |
| Contact Material: | Copper Alloy |
| Housing Material: | Plastic |
| Number of Contacts: | 60 |
| Termination Method: | Solder |
| Flammability Rating: | UL 94V-0 |
| Maximum Operating Temperature: | 125 °C |
| Minimum Operating Temperature: | -55 °C |
| SKU: | HRT09185605923 |
09185605923
Specifications
Detailed Description
SEK Standard Connector, featuring a male design for seamless PCB to cable connection. Crafted from durable beige thermoplastic resin (PBT), this connector offers reliable performance in a range of applications. With wave soldering termination, installation is efficient and secure. Boasting a 60-contact configuration in two rows, it ensures seamless connectivity. The copper alloy contacts with tin over nickel plating guarantee excellent conductivity and durability. Suitable for a wide temperature range from -55°C to 125°C, it's built to withstand harsh environments. With a current rating of 1A and voltage rating of 1kV, it meets stringent performance requirements. Its right-angle mount angle and 2.54mm pitch make it versatile for various PCB setups. UL 94V-0 rated for flammability, it prioritizes safety. Ideal for hi-rel applications, this SEK connector is a dependable choice for demanding electronic systems.
Availability
In Stock:
Call
Stock Location:
In Stock
Factory Stock:
Call for Stock
Factory Lead:
Call
Unit Of Measure:
Each
Minimum/Multiple:
1/1
Invalid quantity value
Documents & Media
Environmental & Export Classifications
| Attribute | Value |
|---|---|
| RoHS Compliant: | Unkown |
