14311116402000

HRT14311116402000
Heilind Number:HRT14311116402000
Manufacturer:HARTING
Manufacturer Number:14311116402000
Datasheet:Datasheet
ECAD Model:
3D Model

Description:

har-flexicon®, Connector; Connector, Horizontal; PA / PPA, Green; PCB to cable; Screw termination; Rated current: 15A; Contacts: 11

More >>

Specifications

AttributeValue
Product Category:
Terminal Blocks PCB Mount Terminal Blocks
Manufacturer:HARTING
Manufacturer Part Number:HARTING 14311116402000
Pitch:5 mm
Series:har-flexicon®
Wire Size:30 - 12 AWG
Mount Angle:Straight
Housing Color:Green
Conductor Size:30 - 12 AWG
Current Rating:15 A
Voltage Rating:250 V
Contact Plating:Tin
Number of Poles:11
Contact Material:Copper Alloy
Housing Material:Nylon
Number of Levels:1
Termination Method:Screw
Flammability Rating:UL 94V-0
Insulation Material:Nylon
Maximum Operating Temperature:110 °C
Minimum Operating Temperature:-40 °C
Part Aliases:
SKU:HRT14311116402000

Detailed Description

The har-flexicon® Connector is a versatile and reliable solution for horizontal PCB to cable connections. With a housing made of durable Nylon in a vibrant Green color, it offers both strength and visual appeal. Featuring screw termination for easy and secure installation, this connector is rated for a maximum current of 15A, making it suitable for a wide range of applications. With 11 contacts and a 5mm pitch, it provides ample connectivity options. The Copper Alloy contacts with Tin plating ensure excellent conductivity and corrosion resistance. Operating temperature ranging from -40°C to 110°C, it is suitable for use in various environments. UL 94V-0 rated for flammability, it meets strict safety standards. Accommodating wire sizes from 30 to 12 AWG, it offers flexibility in design. Overall, the har-flexicon® Connector is a high-quality and efficient solution for your connectivity needs.
