| Attribute | Value |
|---|---|
| Product Category: | |
| Manufacturer: | OTTO Controls |
| Manufacturer Part Number: | OTTO Controls HP7-DR15324 |
| Series: | HP7 |
| Cap Color: | Yellow |
| IP Rating: | IP68S |
| Case Color: | Black |
| Illumination: | Not Illuminated |
| Actuator Type: | Button (Raised Dome) |
| Actuator Shape: | Round |
| Mounting Style: | Panel Mount |
| Actuator Length: | .385 in |
| Housing Material: | Aluminum |
| Type: | Sealed |
| Termination Type: | Wire Leads |
| Actuator Material: | Thermoplastic |
| Durability Rating (Cycles): | 10,000,000 Cycles |
| Voltage Rating (DC): | 3 - 24 VDC |
| Maximum Operating Temperature: | 85 °C |
| Minimum Operating Temperature: | -40 °C |
| SKU: | OTTHP7-DR15324 |
HP7-DR15324
Specifications
Detailed Description
The HP7 Series Yellow Momentary Pushbutton Switch ( HP7-DR15324) offers reliable operation in demanding environments. Featuring an IP68S rating for dust and water resistance, this switch is ideal for industrial applications. The raised dome button actuator with a round shape provides tactile feedback for precise operation. Constructed with a durable aluminum housing and thermoplastic actuator, it ensures long-lasting performance with a durability rating of 10,000,000 cycles. With a voltage rating of 3-24 VDC and an operating temperature range from -40°C to 85°C, it is suitable for a wide range of electronic systems. Perfect for panel mounting, it is easy to install with wire leads termination. Upgrade your control panel with this high-quality sealed pushbutton switch for seamless and efficient operation.
Availability
In Stock:
Call
Stock Location:
In Stock
Factory Stock:
Call for Stock
Factory Lead:
Call
Unit Of Measure:
Each
Minimum/Multiple:
1/1
Invalid quantity value
Documents & Media
Environmental & Export Classifications
| Attribute | Value |
|---|---|
| RoHS Compliant: | Unkown |
