| Attribute | Value |
|---|---|
| Product Category: | |
| Manufacturer: | OTTO Controls |
| Manufacturer Part Number: | OTTO Controls P1-11222 |
| Series: | P1 |
| Cap Color: | Black |
| IP Rating: | Symbol 2 |
| Case Color: | Black |
| Illumination: | Not Illuminated |
| Actuator Type: | Button (Flat) |
| Actuator Shape: | Round |
| Current Rating: | 10 A |
| Mounting Style: | Panel Mount |
| Actuator Length: | .25 in |
| Contact Plating: | Silver |
| Switch Function: | ON-OFF |
| Contact Material: | Brass |
| Housing Material: | Aluminum |
| Type: | Sealed |
| Termination Type: | Solder |
| Actuator Material: | Thermoplastic |
| Durability Rating (Cycles): | 25,000 Cycles |
| Voltage Rating (AC): | 115 VAC |
| Voltage Rating (DC): | 28 VDC |
| Contact Configuration: | SPST-NC |
| Maximum Operating Temperature: | 85 °C |
| Minimum Operating Temperature: | -55 °C |
| SKU: | OTTP1-11222 |
P1-11222
Specifications
Detailed Description
Introducing the Precision Snap-Action Pushbutton Switch, part of our P1 series with SKU P1-11222. Designed for reliability and durability, this switch features a sleek black button actuator with a round shape and flat design. Ideal for panel mounting, it boasts an IP Rating of Symbol 2 for added protection. Operating at 115VAC or 28VDC with a current rating of 10A, it offers a single-pole, normally closed contact configuration. Crafted with brass contacts and silver plating, housed in a sturdy aluminum casing, it ensures high performance in a wide temperature range from -55°C to 85°C. With a lifespan of 25,000 cycles, this sealed switch is perfect for demanding industrial applications. Elevate your control systems with the P111222, the pinnacle of pushbutton technology.
Availability
In Stock:
Call
Stock Location:
In Stock
Factory Stock:
Call for Stock
Factory Lead:
Call
Unit Of Measure:
Each
Minimum/Multiple:
1/1
Invalid quantity value
Documents & Media
Environmental & Export Classifications
| Attribute | Value |
|---|---|
| RoHS Compliant: | Unkown |
