| Attribute | Value |
|---|---|
| Product Category: | |
| Manufacturer: | OTTO Controls |
| Manufacturer Part Number: | OTTO Controls P1-32329 |
| Series: | P1 |
| Cap Color: | White |
| IP Rating: | Symbol 2 |
| Case Color: | Black |
| Illumination: | Not Illuminated |
| Actuator Type: | Button (Flat) |
| Actuator Shape: | Round |
| Current Rating: | 10 A |
| Mounting Style: | Panel Mount |
| Actuator Length: | .25 in |
| Contact Plating: | Silver |
| Switch Function: | ON-OFF |
| Contact Material: | Brass |
| Housing Material: | Aluminum |
| Type: | Sealed |
| Termination Type: | Screw |
| Actuator Material: | Thermoplastic |
| Durability Rating (Cycles): | 25,000 Cycles |
| Voltage Rating (AC): | 115 VAC |
| Voltage Rating (DC): | 28 VDC |
| Contact Configuration: | SPST-NC 3 Terminal |
| Maximum Operating Temperature: | 85 °C |
| Minimum Operating Temperature: | -55 °C |
| SKU: | OTTP1-32329 |
P1-32329
Specifications
Detailed Description
Introducing the P1-32329, a high-performance pushbutton switch from the P1 series. Featuring a sleek design with a white button cap and a durable black aluminum housing, this switch is perfect for panel mounting. The SPST-NC 3 terminal configuration ensures reliable operation, with a silver-plated brass contact providing excellent conductivity. With a 10A current rating and a voltage rating of 115VAC/28VDC, it is suitable for a wide range of applications. The precision snap-action mechanism guarantees a smooth and responsive user experience, with a long lifespan of 25,000 cycles. Operating reliably in temperatures ranging from -55°C to 85°C, this sealed switch is ideal for use in demanding environments. Upgrade your control systems with the P1-32329 for superior performance and durability.
Availability
In Stock:
Call
Stock Location:
In Stock
Factory Stock:
Call for Stock
Factory Lead:
Call
Unit Of Measure:
Each
Minimum/Multiple:
1/1
Invalid quantity value
Documents & Media
Environmental & Export Classifications
| Attribute | Value |
|---|---|
| RoHS Compliant: | Unkown |
