| Attribute | Value |
|---|---|
| Product Category: | |
| Manufacturer: | OTTO Controls |
| Manufacturer Part Number: | OTTO Controls P1-33129 |
| Series: | P1 |
| Cap Color: | White |
| IP Rating: | Symbol 2 |
| Case Color: | Black |
| Illumination: | Not Illuminated |
| Actuator Type: | Button (Flat) |
| Actuator Shape: | Round |
| Current Rating: | 10 mA |
| Mounting Style: | Panel Mount |
| Actuator Length: | .25 in |
| Contact Plating: | Gold |
| Switch Function: | OFF-ON |
| Contact Material: | Brass |
| Housing Material: | Aluminum |
| Type: | Sealed |
| Termination Type: | Solder |
| Actuator Material: | Thermoplastic |
| Durability Rating (Cycles): | 50,000 Cycles |
| Voltage Rating (DC): | 5 VDC |
| Contact Configuration: | SPST-NO |
| Maximum Operating Temperature: | 85 °C |
| Minimum Operating Temperature: | -55 °C |
| SKU: | OTTP1-33129 |
P1-33129
Specifications
Detailed Description
Introducing the Precision Snap-Action Pushbutton Switch, part of the P1 series. This high-quality switch features a durable aluminum housing in sleek black, with a flat white button for easy actuation. Its sealed construction and IP Rating 2 make it ideal for reliable performance in various environments. The switch operates on a low 10mA current, with gold-plated brass contacts ensuring optimal conductivity. Designed for panel mounting with solder termination, it offers a long lifespan of 50,000 cycles. With a voltage rating of 5VDC and operating temperatures ranging from -55°C to 85°C, this switch guarantees efficient functionality. Perfect for applications requiring a momentary Off-(On) switch, the P133129 is a dependable choice in the realm of Push Button Switches.
Availability
In Stock:
Call
Stock Location:
In Stock
Factory Stock:
Call for Stock
Factory Lead:
Call
Unit Of Measure:
Each
Minimum/Multiple:
1/1
Invalid quantity value
Documents & Media
Environmental & Export Classifications
| Attribute | Value |
|---|---|
| RoHS Compliant: | Unkown |
