| Attribute | Value |
|---|---|
| Product Category: | |
| Manufacturer: | OTTO Controls |
| Manufacturer Part Number: | OTTO Controls P1-72234 |
| Series: | P1 |
| Cap Color: | Yellow |
| IP Rating: | Symbol 2 |
| Case Color: | Black |
| Illumination: | Not Illuminated |
| Actuator Type: | Button (Flat) |
| Actuator Shape: | Round |
| Current Rating: | 10 A |
| Mounting Style: | Panel Mount |
| Actuator Length: | .25 in |
| Contact Plating: | Silver |
| Switch Function: | ON-OFF |
| Contact Material: | Brass |
| Housing Material: | Aluminum |
| Type: | Sealed |
| Termination Type: | Screw |
| Actuator Material: | Thermoplastic |
| Durability Rating (Cycles): | 25,000 Cycles |
| Voltage Rating (AC): | 115 VAC |
| Voltage Rating (DC): | 28 VDC |
| Contact Configuration: | SPST-NC |
| Maximum Operating Temperature: | 85 °C |
| Minimum Operating Temperature: | -55 °C |
| SKU: | OTTP1-72234 |
P1-72234
Specifications
Detailed Description
Introducing the P1-72234, a high-performance pushbutton switch from the P1 series. Featuring a sleek design with a yellow flat button actuator, this switch is perfect for panel mounting applications. With an IP rating of Symbol 2 and a durable aluminum housing, it ensures reliable operation in demanding environments. The SPST-NC contact configuration and silver-plated brass contacts guarantee efficient and long-lasting performance. Operating at a maximum temperature of 85°C and a minimum of -55°C, it offers versatility in usage. Rated for 10A at 115VAC and 28VDC, it's suitable for various power applications. With a 25,000-cycle durability rating, this switch is built to last. Experience precision and reliability with the P1-72234 Pushbutton Switch.
Availability
In Stock:
Call
Stock Location:
In Stock
Factory Stock:
Call for Stock
Factory Lead:
Call
Unit Of Measure:
Each
Minimum/Multiple:
1/1
Invalid quantity value
Documents & Media
Environmental & Export Classifications
| Attribute | Value |
|---|---|
| RoHS Compliant: | Unkown |
