| Attribute | Value |
|---|---|
| Product Category: | |
| Manufacturer: | OTTO Controls |
| Manufacturer Part Number: | OTTO Controls P1-72632 |
| Series: | P1 |
| Cap Color: | Black |
| IP Rating: | Symbol 2 |
| Case Color: | Black |
| Illumination: | Not Illuminated |
| Actuator Type: | Button (Flat) |
| Actuator Shape: | Round |
| Current Rating: | 10 A |
| Mounting Style: | Panel Mount |
| Actuator Length: | .25 in |
| Contact Plating: | Silver |
| Switch Function: | ON-ON |
| Contact Material: | Brass |
| Housing Material: | Aluminum |
| Type: | Sealed |
| Termination Type: | Screw |
| Actuator Material: | Thermoplastic |
| Durability Rating (Cycles): | 25,000 Cycles |
| Voltage Rating (AC): | 115 VAC |
| Voltage Rating (DC): | 28 VDC |
| Contact Configuration: | SPDT |
| Maximum Operating Temperature: | 85 °C |
| Minimum Operating Temperature: | -55 °C |
| SKU: | OTTP1-72632 |
P1-72632
Specifications
Detailed Description
The P1-72632 Precision Snap-Action Pushbutton Switch in the P1 series is a reliable and durable component designed for panel mount installation. Featuring a sleek black aluminum housing with a matching black flat button actuator, this switch offers a seamless integration into various devices and machinery. With an IP rating of Symbol 2 and sealed construction, it ensures optimal performance even in challenging environments. The SPDT contact configuration, along with a 10A current rating, guarantees efficient power control. Operating between -55°C to 85°C, it is suitable for a wide range of applications. With a lifespan of 25,000 cycles, this switch is built to last. Whether for industrial machinery or consumer electronics, the P1-72632 is a versatile solution that combines high performance with longevity.
Availability
In Stock:
Call
Stock Location:
In Stock
Factory Stock:
Call for Stock
Factory Lead:
Call
Unit Of Measure:
Each
Minimum/Multiple:
1/1
Invalid quantity value
Documents & Media
Environmental & Export Classifications
| Attribute | Value |
|---|---|
| RoHS Compliant: | Unkown |
