| Attribute | Value |
|---|---|
| Product Category: | |
| Manufacturer: | OTTO Controls |
| Manufacturer Part Number: | OTTO Controls P1-73618 |
| Series: | P1 |
| Housing Material: | Aluminum |
| Contact Material: | Brass |
| Contact Plating: | Gold |
| Maximum Operating Temperature: | 85 °C |
| Minimum Operating Temperature: | -55 °C |
| IP Rating: | Symbol 2 |
| Illumination: | Not Illuminated |
| Contact Configuration: | SPDT |
| Actuator Type: | Button (Flat) |
| Case Color: | Black |
| Actuator Material: | Thermoplastic |
| Termination Type: | Solder |
| Actuator Shape: | Round |
| Cap Color: | Gray |
| Actuator Length: | .25 in |
| Switch Function: | ON-ON |
| Type: | Sealed |
| Durability Rating (Cycles): | 25,000 Cycles |
| Mounting Style: | Panel Mount |
| Current Rating: | 10 mA |
| Voltage Rating (DC): | 30 mV |
| SKU: | OTTP1-73618 |
P1-73618
Specifications
Detailed Description
Introducing the P1-73618, a high-performance Pushbutton Switch from our P1 series. Designed for precision and durability, this switch features a flat round button actuator with a gray cap and black housing, making it suitable for panel mounting. With a sealed construction and an IP rating of 2, it ensures reliable operation even in challenging environments. The SPDT contact configuration, with gold-plated brass contacts, guarantees efficient conductivity. Rated for a current of 10mA and a voltage of 30mV DC, this switch is perfect for a variety of applications. Operating smoothly between -55°C to 85°C, and with a lifespan of 25,000 cycles, it provides long-lasting performance. Ideal for industrial and commercial use, the P1-73618 is the epitome of quality and functionality in pushbutton switches.
Availability
In Stock:
Call
Stock Location:
In Stock
Factory Stock:
Call for Stock
Factory Lead:
Call
Unit Of Measure:
Each
Minimum/Multiple:
1/1
Invalid quantity value
Documents & Media
Environmental & Export Classifications
| Attribute | Value |
|---|---|
| RoHS Compliant: | Unkown |
