| Attribute | Value |
|---|---|
| Product Category: | |
| Manufacturer: | OTTO Controls |
| Manufacturer Part Number: | OTTO Controls P1-81129 |
| Series: | P1 |
| Housing Material: | Aluminum |
| Contact Material: | Brass |
| Contact Plating: | Silver |
| Maximum Operating Temperature: | 85 °C |
| Minimum Operating Temperature: | -55 °C |
| IP Rating: | Symbol 2 |
| Illumination: | Not Illuminated |
| Contact Configuration: | SPST-NO |
| Actuator Type: | Button (Flat) |
| Case Color: | Black |
| Actuator Material: | Thermoplastic |
| Termination Type: | Solder |
| Actuator Shape: | Round |
| Cap Color: | White |
| Actuator Length: | .25 in |
| Switch Function: | OFF-ON |
| Type: | Sealed |
| Durability Rating (Cycles): | 25,000 Cycles |
| Mounting Style: | Panel Mount |
| Current Rating: | 10 A |
| Voltage Rating (AC): | 115 VAC |
| Voltage Rating (DC): | 28 VDC |
| SKU: | OTTP1-81129 |
P1-81129
Specifications
Detailed Description
Meet the P1-81129, part of the P1 series, a precision Snap-Action Pushbutton Switch designed for optimal performance. Featuring a sleek White cap and durable Black casing, this switch boasts an IP Rating of 2, ensuring reliability in various environments. The Button (Flat) actuator, made of Thermoplastic, offers a comfortable tactile experience. With a contact plating of Silver and contact material of Brass, it guarantees efficient conductivity. Operating at 115 VAC or 28 VDC with a current rating of 10 A, this SPST-NO configuration switch is perfect for panel mounting applications. Its sealed housing, along with a durability rating of 25,000 cycles, ensures long-lasting use. Suitable for temperatures ranging from -55°C to 85°C, the P1-81129 is the ideal choice for demanding industrial settings.
Availability
In Stock:
Call
Stock Location:
In Stock
Factory Stock:
Call for Stock
Factory Lead:
Call
Unit Of Measure:
Each
Minimum/Multiple:
1/1
Invalid quantity value
Documents & Media
Environmental & Export Classifications
| Attribute | Value |
|---|---|
| RoHS Compliant: | Unkown |
