P3-82211

OTTP3_82211
Heilind Number:OTTP3-82211
Manufacturer:OTTO Controls
Manufacturer Number:P3-82211
Datasheet:Datasheet
ECAD Model:
3D Model

Description:

Sealed Momentary Action Pushbutton

More >>

Specifications

AttributeValue
Product Category:
Switches Push Button Switches
Manufacturer:OTTO Controls
Manufacturer Part Number:OTTO Controls P3-82211
Series:P3
Cap Color:Red
IP Rating:IP6K4S
Case Color:Silver
Illumination:Not Illuminated
Actuator Type:Button (Flat)
Actuator Shape:Round
Current Rating:10 A
Mounting Style:Panel Mount
Actuator Length:.25 in
Contact Plating:Silver
Switch Function:ON-OFF
Contact Material:Brass
Housing Material:Aluminum
Type:Sealed
Termination Type:Screw
Actuator Material:Nylon
Durability Rating (Cycles):100,000 Cycles
Voltage Rating (AC):115 VAC
Voltage Rating (DC):28 VDC
Contact Configuration:SPST-NC
Maximum Operating Temperature:85 °C
Minimum Operating Temperature:-55 °C
SKU:OTTP3-82211

Detailed Description

The P3-82211 Pushbutton Switch from the P3 series is a high-quality, durable component designed for reliable performance in demanding environments. Featuring a red button cap and a sleek silver case, this switch not only offers a striking visual appeal but also ensures IP6K4S sealing, making it resistant to dust and water ingress. With a 10A current rating, it's suitable for a variety of applications. The flat round button actuator, made of nylon, provides comfortable operation, while the brass contact material guarantees excellent conductivity. Perfect for panel mounting, this switch is SPST-NC configured for on-(off) functions, with a voltage rating of 115VAC and 28VDC. With a wide operating temperature range of -55°C to 85°C and a durability rating of 100,000 cycles, the P3-82211 is a reliable choice for industrial and commercial settings.
