P3-82218

OTTP3_82218
Heilind Number:OTTP3-82218
Manufacturer:OTTO Controls
Manufacturer Number:P3-82218
Datasheet:Datasheet
ECAD Model:
3D Model

Description:

Sealed Momentary Action Pushbutton

More >>

Specifications

AttributeValue
Product Category:
Switches Push Button Switches
Manufacturer:OTTO Controls
Manufacturer Part Number:OTTO Controls P3-82218
Series:P3
Housing Material:Aluminum
Contact Material:Brass
Contact Plating:Silver
Maximum Operating Temperature:85 °C
Minimum Operating Temperature:-55 °C
IP Rating:IP6K4S
Illumination:Not Illuminated
Contact Configuration:SPST-NC
Actuator Type:Button (Flat)
Case Color:Silver
Actuator Material:Nylon
Termination Type:Screw
Actuator Shape:Round
Cap Color:Gray
Actuator Length:.25 in
Switch Function:ON-OFF
Type:Sealed
Durability Rating (Cycles):100,000 Cycles
Mounting Style:Panel Mount
Current Rating:10 A
Voltage Rating (AC):115 VAC
Voltage Rating (DC):28 VDC
SKU:OTTP3-82218

Detailed Description

Introducing the P3 Series Sealed Momentary Action Pushbutton Switch, SKU P3-82218. Designed for reliable performance in demanding environments, this switch features a durable aluminum housing with a sleek silver case. The gray flat button actuator, made of nylon, provides a comfortable and responsive interface. With an IP6K4S rating, it offers protection against dust and water ingress, making it ideal for outdoor or industrial applications. The SPST-NC contact configuration ensures a secure connection, while the silver contact plating guarantees high conductivity. Operating at temperatures ranging from -55°C to 85°C, and with a 100,000-cycle durability rating, this switch is built to withstand tough conditions. Suitable for panel mounting, it has a maximum voltage rating of 115VAC and 28VDC, with a current rating of 10A. Perfect for use in aerospace, automotive, or industrial settings, the P3 Series Pushbutton Switch combines performance and durability in a compact and reliable package.
