| Attribute | Value |
|---|---|
| Product Category: | |
| Manufacturer: | OTTO Controls |
| Manufacturer Part Number: | OTTO Controls P3-82625 |
| Series: | P3 |
| Cap Color: | Green |
| IP Rating: | IP6K4S |
| Case Color: | Silver |
| Illumination: | Not Illuminated |
| Actuator Type: | Button (Flat) |
| Actuator Shape: | Round |
| Current Rating: | 10 A |
| Mounting Style: | Panel Mount |
| Actuator Length: | .25 in |
| Contact Plating: | Silver |
| Switch Function: | ON-ON |
| Contact Material: | Brass |
| Housing Material: | Aluminum |
| Type: | Sealed |
| Termination Type: | Screw |
| Actuator Material: | Nylon |
| Durability Rating (Cycles): | 100,000 Cycles |
| Voltage Rating (AC): | 115 VAC |
| Voltage Rating (DC): | 28 VDC |
| Contact Configuration: | SPDT |
| Maximum Operating Temperature: | 85 °C |
| Minimum Operating Temperature: | -55 °C |
| SKU: | OTTP3-82625 |
P3-82625
Specifications
Detailed Description
Introducing the P3-82625, a durable and reliable sealed momentary action pushbutton from the P3 series. This high-performance switch features a green flat round button actuator, perfect for panel mounting. With an IP6K4S rating, it guarantees protection against dust and water ingress, making it ideal for demanding environments. The silver aluminum housing and brass contacts ensure longevity, with a durability rating of 100,000 cycles. Operating at temperatures ranging from -55°C to 85°C, it offers versatility. The SPDT contact configuration, rated for 10A at 115VAC and 28VDC, suits various applications. Trust in the P382625 for efficient and precise switching in industrial settings.
Availability
In Stock:
Call
Stock Location:
In Stock
Factory Stock:
Call for Stock
Factory Lead:
Call
Unit Of Measure:
Each
Minimum/Multiple:
1/1
Invalid quantity value
Documents & Media
Environmental & Export Classifications
| Attribute | Value |
|---|---|
| RoHS Compliant: | Unkown |
