| Attribute | Value |
|---|---|
| Product Category: | |
| Manufacturer: | OTTO Controls |
| Manufacturer Part Number: | OTTO Controls P3-84126W |
| Series: | P3 |
| Housing Material: | Aluminum |
| Contact Material: | Brass |
| Contact Plating: | Gold |
| Maximum Operating Temperature: | 85 °C |
| Minimum Operating Temperature: | -55 °C |
| IP Rating: | IP6K8S |
| Illumination: | Not Illuminated |
| Contact Configuration: | SPST-NO |
| Actuator Type: | Button (Flat) |
| Case Color: | Silver |
| Actuator Material: | Nylon |
| Termination Type: | Screw |
| Actuator Shape: | Round |
| Cap Color: | Blue |
| Actuator Length: | .25 in |
| Switch Function: | OFF-ON |
| Type: | Sealed |
| Durability Rating (Cycles): | 100,000 Cycles |
| Mounting Style: | Panel Mount |
| Current Rating: | 10 A |
| Voltage Rating (AC): | 115 VAC |
| Voltage Rating (DC): | 28 VDC |
| SKU: | OTTP3-84126W |
P3-84126W
Specifications
Detailed Description
Introducing the P3 Series Sealed Momentary Action Pushbutton Switch with SKU P3-84126W. This durable and reliable switch features a blue button cap and silver housing, making it suitable for various panel mount applications. With an IP6K8S rating, it ensures protection against dust and water ingress. The flat round button offers a comfortable actuation experience, while the SPST-NO contact configuration and 10A current rating guarantee efficient performance. Gold-plated brass contacts and aluminum housing enhance durability, with a lifespan of 100,000 cycles. Operating at temperatures ranging from -55°C to 85°C and accommodating voltage ratings of 115VAC and 28VDC, this switch is ideal for demanding industrial environments. Trust in the P3 Series for quality and longevity in your electrical control systems.
Availability
In Stock:
Call
Stock Location:
In Stock
Factory Stock:
Call for Stock
Factory Lead:
Call
Unit Of Measure:
Each
Minimum/Multiple:
1/1
Invalid quantity value
Documents & Media
Environmental & Export Classifications
| Attribute | Value |
|---|---|
| RoHS Compliant: | Unkown |
