| Attribute | Value |
|---|---|
| Product Category: | |
| Manufacturer: | OTTO Controls |
| Manufacturer Part Number: | OTTO Controls P3-D221124 |
| Series: | P3-D |
| Cap Color: | Yellow |
| IP Rating: | IP6K4S |
| Case Color: | Black |
| Illumination: | Not Illuminated |
| Actuator Type: | Button (Raised Dome) |
| Actuator Shape: | Round |
| Current Rating: | 10 A |
| Mounting Style: | Panel Mount |
| Actuator Length: | .53 in |
| Contact Plating: | Silver |
| Switch Function: | OFF-ON |
| Contact Material: | Brass |
| Housing Material: | Aluminum |
| Type: | Sealed |
| Termination Type: | Screw |
| Actuator Material: | Thermoplastic |
| Durability Rating (Cycles): | 100,000 Cycles |
| Voltage Rating (AC): | 115 VAC |
| Voltage Rating (DC): | 28 VDC |
| Contact Configuration: | SPST-NO |
| Maximum Operating Temperature: | 85 °C |
| Minimum Operating Temperature: | -55 °C |
| SKU: | OTTP3-D221124 |
P3-D221124
Specifications
Detailed Description
Introducing the P3-D Series Dome Style Pushbutton Switch, featuring a durable design with an IP6K4S sealing rating for reliable performance in harsh environments. This panel-mount switch, with a sleek black housing and a vibrant yellow button, offers a momentary action with a 10A current rating. The raised dome button, made of thermoplastic, provides tactile feedback and easy actuation. With a contact configuration of SPST-NO and silver contact plating, it ensures efficient conductivity. Operating at temperatures ranging from -55°C to 85°C, and compatible with AC and DC voltages of up to 115V and 28V respectively, this switch is ideal for various industrial applications. Its long-lasting durability of 100,000 cycles guarantees longevity, making it a reliable choice for demanding settings.
Availability
In Stock:
Call
Stock Location:
In Stock
Factory Stock:
Call for Stock
Factory Lead:
Call
Unit Of Measure:
Each
Minimum/Multiple:
1/1
Invalid quantity value
Documents & Media
Environmental & Export Classifications
| Attribute | Value |
|---|---|
| RoHS Compliant: | Unkown |
