| Attribute | Value |
|---|---|
| Product Category: | |
| Manufacturer: | OTTO Controls |
| Manufacturer Part Number: | OTTO Controls P3-D231222 |
| Series: | P3-D |
| Cap Color: | Black |
| IP Rating: | IP6K4S |
| Case Color: | Black |
| Illumination: | Not Illuminated |
| Actuator Type: | Button (Raised Dome) |
| Actuator Shape: | Round |
| Current Rating: | 10 A |
| Mounting Style: | Panel Mount |
| Actuator Length: | .53 in |
| Contact Plating: | Gold |
| Switch Function: | OFF-ON |
| Contact Material: | Brass |
| Housing Material: | Aluminum |
| Type: | Sealed |
| Termination Type: | Solder |
| Actuator Material: | Thermoplastic |
| Durability Rating (Cycles): | 100,000 Cycles |
| Voltage Rating (AC): | 115 VAC |
| Voltage Rating (DC): | 28 VDC |
| Contact Configuration: | SPST-NO |
| Maximum Operating Temperature: | 85 °C |
| Minimum Operating Temperature: | -55 °C |
| SKU: | OTTP3-D231222 |
P3-D231222
Specifications
Detailed Description
Introducing the P3-D231222, a high-performance pushbutton switch designed for durability and reliability in demanding environments. With a sleek black cap and case, this switch features a raised dome button for tactile feedback. Boasting an IP6K4S rating, it is sealed against dust and moisture ingress, making it ideal for outdoor or industrial use. The gold-plated contacts ensure efficient signal transfer, while the brass actuator and aluminum housing guarantee robustness. This SPST-NO switch offers a momentary off-(on) function, with a 10A current rating and 115VAC/28VDC voltage ratings. Operating smoothly from -55°C to 85°C, it is suitable for a wide range of applications. Trust in the P3-D231222 for precision control and long-lasting performance.
Availability
In Stock:
Call
Stock Location:
In Stock
Factory Stock:
Call for Stock
Factory Lead:
Call
Unit Of Measure:
Each
Minimum/Multiple:
1/1
Invalid quantity value
Documents & Media
Environmental & Export Classifications
| Attribute | Value |
|---|---|
| RoHS Compliant: | Unkown |
