| Attribute | Value |
|---|---|
| Product Category: | |
| Manufacturer: | OTTO Controls |
| Manufacturer Part Number: | OTTO Controls P4-423124 |
| Series: | P4 |
| Cap Color: | Yellow |
| Case Color: | Black |
| Illumination: | Not Illuminated |
| Actuator Type: | Button (Flat) |
| Actuator Shape: | Round |
| Current Rating: | 5 A |
| Mounting Style: | Panel Mount |
| Actuator Length: | .25 in |
| Contact Plating: | Gold |
| Contact Material: | Silver |
| Housing Material: | Aluminum |
| Type: | Sealed |
| Termination Type: | Solder |
| Actuator Material: | Thermoplastic |
| Durability Rating (Cycles): | 25,000 Cycles |
| Voltage Rating (DC): | 28 VDC |
| Contact Configuration: | DPDT 6 Terminal |
| Maximum Operating Temperature: | 85 °C |
| Minimum Operating Temperature: | -40 °C |
| SKU: | OTTP4-423124 |
P4-423124
Specifications
Detailed Description
Introducing the P4 Series Auxiliary Actuators, featuring a striking Yellow cap and sleek Black case design. These Panel Mount push buttons, with a durable aluminum housing and thermoplastic actuator, offer reliable performance in various applications. With a current rating of 5A and a voltage rating of 28VDC, they ensure efficient operation. The DPDT 6 Terminal contact configuration and gold plating guarantee optimal conductivity. The non-illuminated, two-step custom pushbutton, with a round flat button actuator, provides smooth and precise control. Its sealed construction and -40°C to 85°C operating temperature range make it suitable for diverse environments. Boasting a 25,000-cycle durability rating, these switches are built to last. Perfect for industrial, automotive, or aerospace use, the P4 Series sets a new standard in push button switches.
Availability
In Stock:
Call
Stock Location:
In Stock
Factory Stock:
Call for Stock
Factory Lead:
Call
Unit Of Measure:
Each
Minimum/Multiple:
1/1
Invalid quantity value
Documents & Media
Environmental & Export Classifications
| Attribute | Value |
|---|---|
| RoHS Compliant: | Unkown |
