| Attribute | Value |
|---|---|
| Product Category: | |
| Manufacturer: | OTTO Controls |
| Manufacturer Part Number: | OTTO Controls P4-433119 |
| Series: | P4 |
| Cap Color: | White |
| Case Color: | Black |
| Illumination: | Not Illuminated |
| Actuator Type: | Button (Flat) |
| Actuator Shape: | Round |
| Current Rating: | 5 A |
| Mounting Style: | Panel Mount |
| Actuator Length: | .25 in |
| Contact Plating: | Gold |
| Contact Material: | Silver |
| Housing Material: | Aluminum |
| Type: | Sealed |
| Termination Type: | Wire Wrap |
| Actuator Material: | Thermoplastic |
| Durability Rating (Cycles): | 25,000 Cycles |
| Voltage Rating (DC): | 28 VDC |
| Contact Configuration: | DPDT 6 Terminal |
| Maximum Operating Temperature: | 85 °C |
| Minimum Operating Temperature: | -40 °C |
| SKU: | OTTP4-433119 |
P4-433119
Specifications
Detailed Description
Introducing the P4-433119, a high-quality push button switch from our P4 series. This sleek and durable switch features a white button cap and a black aluminum housing, making it both visually appealing and reliable. With a non-illuminated design and a round flat actuator, it offers a comfortable and efficient user experience. The DPDT 6 terminal contact configuration, along with a 5A current rating and 28VDC voltage rating, ensure versatile application possibilities. Engineered for durability with a 25,000 cycle lifespan and operating temperatures ranging from -40°C to 85°C, this sealed switch is perfect for demanding environments. Its wire wrap termination and panel mount installation make it easy to integrate into your project. Upgrade your control systems with the P4-433119, where quality meets performance.
Availability
In Stock:
Call
Stock Location:
In Stock
Factory Stock:
Call for Stock
Factory Lead:
Call
Unit Of Measure:
Each
Minimum/Multiple:
1/1
Invalid quantity value
Documents & Media
Environmental & Export Classifications
| Attribute | Value |
|---|---|
| RoHS Compliant: | Unkown |
