| Attribute | Value |
|---|---|
| Product Category: | |
| Manufacturer: | OTTO Controls |
| Manufacturer Part Number: | OTTO Controls P5-412221 |
| Series: | P5 |
| Housing Material: | Aluminum |
| Contact Material: | Brass |
| Contact Plating: | Gold |
| Maximum Operating Temperature: | 85 °C |
| Minimum Operating Temperature: | -40 °C |
| IP Rating: | Symbol 2 |
| Illumination: | Not Illuminated |
| Contact Configuration: | SPST |
| Actuator Type: | Button (Flat) |
| Case Color: | Black |
| Actuator Material: | Thermoplastic |
| Termination Type: | Solder |
| Actuator Shape: | Round |
| Cap Color: | Red |
| Actuator Length: | .32 in |
| Switch Function: | Off-On |
| Type: | Sealed |
| Durability Rating (Cycles): | 25,000 Cycles |
| Mounting Style: | Panel Mount |
| Current Rating: | 10 - 100 mA |
| Voltage Rating (DC): | 3 - 28 VDC |
| SKU: | OTTP5-412221 |
P5-412221
Specifications
Detailed Description
Introducing the P5-412221, a high-performance pushbutton switch designed for demanding environments. With a rugged aluminum housing and sealed construction, this Mil Grade switch offers exceptional durability and reliability. The red button with a flat round actuator provides easy tactile feedback, while the gold-plated brass contacts ensure optimal conductivity. Operating at a voltage range of 3-28 VDC and a current rating of 10-100 mA, it is suitable for a wide range of applications. The Off-On switch function and SPST contact configuration make it versatile for various control systems. Whether in aerospace, military, or industrial settings, this switch guarantees long-lasting performance even in extreme temperatures from -40°C to 85°C. Upgrade to the P5 series for a dependable solution in critical operations.
Availability
In Stock:
Call
Stock Location:
In Stock
Factory Stock:
Call for Stock
Factory Lead:
Call
Unit Of Measure:
Each
Minimum/Multiple:
1/1
Invalid quantity value
Documents & Media
Environmental & Export Classifications
| Attribute | Value |
|---|---|
| RoHS Compliant: | Unkown |
