| Attribute | Value |
|---|---|
| Product Category: | |
| Manufacturer: | OTTO Controls |
| Manufacturer Part Number: | OTTO Controls P7-131124 |
| Series: | P7 |
| Cap Color: | Yellow |
| IP Rating: | Symbol 3 |
| Case Color: | Black |
| Illumination: | Not Illuminated |
| Actuator Type: | Button (Flat) |
| Actuator Shape: | Round |
| Current Rating: | 5 A |
| Mounting Style: | Panel Mount |
| Actuator Length: | .08 in |
| Contact Plating: | Gold |
| Switch Function: | OFF-ON |
| Contact Material: | Brass |
| Housing Material: | Aluminum |
| Type: | Sealed |
| Termination Type: | Solder |
| Actuator Material: | Thermoplastic |
| Durability Rating (Cycles): | 50,000 Cycles |
| Voltage Rating (AC): | 115 VAC |
| Voltage Rating (DC): | 28 VDC |
| Contact Configuration: | SPST-NO |
| Maximum Operating Temperature: | 85 °C |
| Minimum Operating Temperature: | -55 °C |
| SKU: | OTTP7-131124 |
P7-131124
Specifications
Detailed Description
The P7-131124 Push Button Switch, part of the P7 series, boasts a durable design with a yellow flat button actuator and sealed construction for reliable performance in demanding environments. Featuring a black aluminum housing and gold-plated brass contacts, this switch ensures longevity with a 50,000-cycle durability rating. Ideal for panel mounting, it offers a 5A current rating and is suitable for both AC (115V) and DC (28V) applications. With an IP3 rating, it provides limited protection against water and dust ingress. The SPST-NO configuration and momentary action make it perfect for applications requiring a quick on-off function. Operating smoothly in temperatures ranging from -55°C to 85°C, this subminiature switch is a dependable choice for industrial and commercial use.
Availability
In Stock:
Call
Stock Location:
In Stock
Factory Stock:
Call for Stock
Factory Lead:
Call
Unit Of Measure:
Each
Minimum/Multiple:
1/1
Invalid quantity value
Documents & Media
Environmental & Export Classifications
| Attribute | Value |
|---|---|
| RoHS Compliant: | Unkown |
