| Attribute | Value |
|---|---|
| Product Category: | |
| Manufacturer: | OTTO Controls |
| Manufacturer Part Number: | OTTO Controls P7-536128 |
| Series: | P7 |
| Cap Color: | Gray |
| IP Rating: | Symbol 3 |
| Case Color: | Black |
| Illumination: | Not Illuminated |
| Actuator Type: | Button (Flat) |
| Actuator Shape: | Round |
| Current Rating: | 5 A |
| Mounting Style: | Panel Mount |
| Actuator Length: | .08 in |
| Contact Plating: | Gold |
| Switch Function: | ON-ON |
| Contact Material: | Brass |
| Housing Material: | Aluminum |
| Type: | Sealed |
| Termination Type: | Solder |
| Actuator Material: | Thermoplastic |
| Durability Rating (Cycles): | 50,000 Cycles |
| Voltage Rating (AC): | 115 VAC |
| Voltage Rating (DC): | 28 VDC |
| Contact Configuration: | SPDT |
| Maximum Operating Temperature: | 85 °C |
| Minimum Operating Temperature: | -55 °C |
| SKU: | OTTP7-536128 |
P7-536128
Specifications
Detailed Description
P7-536128, the P7 series Subminiature Momentary Action Pushbutton Switch is designed for high reliability applications. Featuring a durable aluminum housing with a black case and a flat gray button, this sealed switch is ideal for panel mounting. The SPDT contact configuration with gold-plated brass contacts ensures high conductivity and a long lifespan of 50,000 cycles. With a current rating of 5A, voltage ratings of 115VAC and 28VDC, and an operating temperature range from -55°C to 85°C, this switch offers reliable performance in a wide range of environments. The compact design, with an actuator length of .08 inches, makes it suitable for use in tight spaces. Perfect for industrial and commercial use, the P7 Pushbutton Switch is a dependable choice for critical control applications.
Availability
In Stock:
Call
Stock Location:
In Stock
Factory Stock:
Call for Stock
Factory Lead:
Call
Unit Of Measure:
Each
Minimum/Multiple:
1/1
Invalid quantity value
Documents & Media
Environmental & Export Classifications
| Attribute | Value |
|---|---|
| RoHS Compliant: | Unkown |
