| Attribute | Value |
|---|---|
| Product Category: | |
| Manufacturer: | OTTO Controls |
| Manufacturer Part Number: | OTTO Controls P7-551129 |
| Series: | P7 |
| Housing Material: | Aluminum |
| Contact Material: | Brass |
| Contact Plating: | Gold |
| Maximum Operating Temperature: | 85 °C |
| Minimum Operating Temperature: | -55 °C |
| IP Rating: | Symbol 2 |
| Illumination: | Not Illuminated |
| Contact Configuration: | SPST-NO |
| Actuator Type: | Button (Flat) |
| Case Color: | Black |
| Actuator Material: | Thermoplastic |
| Termination Type: | PC Pin |
| Actuator Shape: | Round |
| Cap Color: | White |
| Actuator Length: | .08 in |
| Switch Function: | OFF-ON |
| Type: | Sealed |
| Durability Rating (Cycles): | 50,000 Cycles |
| Mounting Style: | Panel Mount |
| Current Rating: | 5 A |
| Voltage Rating (AC): | 115 VAC |
| Voltage Rating (DC): | 28 VDC |
| SKU: | OTTP7-551129 |
P7-551129
Specifications
Detailed Description
Introducing the P7 Series Subminiature Momentary Action Pushbutton Switch, featuring a sleek black aluminum case with a flat white button for easy operation. Designed for durability with a 50,000-cycle lifespan, this sealed switch ensures reliable performance in various environments. The SPST-NO contact configuration, with brass contacts plated in gold, guarantees efficient conductivity. Operating at temperatures from -55°C to 85°C, it is suitable for a wide range of applications. With a 5A current rating, 115VAC and 28VDC voltage ratings, and a panel mount installation, this switch offers versatility in usage. Perfect for industrial, automotive, or electronic projects requiring a high-quality push button switch, the P7 Series is your go-to solution for dependable control.
Availability
In Stock:
Call
Stock Location:
In Stock
Factory Stock:
Call for Stock
Factory Lead:
Call
Unit Of Measure:
Each
Minimum/Multiple:
1/1
Invalid quantity value
Documents & Media
Environmental & Export Classifications
| Attribute | Value |
|---|---|
| RoHS Compliant: | Unkown |
