P7-AA1126

OTTP7_AA1126
Heilind Number:OTTP7-AA1126
Manufacturer:OTTO Controls
Manufacturer Number:P7-AA1126
Datasheet:Datasheet
ECAD Model:
3D Model

Description:

Subminiature Momentary Action Pushbutton Switch

More >>

Specifications

AttributeValue
Product Category:
Switches Push Button Switches
Manufacturer:OTTO Controls
Manufacturer Part Number:OTTO Controls P7-AA1126
Series:P7
Housing Material:Aluminum
Contact Material:Brass
Contact Plating:Gold
Maximum Operating Temperature:85 °C
Minimum Operating Temperature:-55 °C
IP Rating:IP6K4S
Illumination:Not Illuminated
Contact Configuration:SPST-NO
Actuator Type:Button (Raised)
Case Color:Black
Actuator Material:Thermoplastic
Termination Type:Solder
Actuator Shape:Round
Cap Color:Blue
Actuator Length:.041 in
Switch Function:OFF-ON
Type:Sealed
Durability Rating (Cycles):50,000 Cycles
Mounting Style:Panel Mount
Current Rating:5 A
Voltage Rating (AC):115 VAC
Voltage Rating (DC):28 VDC
SKU:OTTP7-AA1126

Detailed Description

The P7 Series Subminiature Momentary Action Pushbutton Switch, with SKU P7-AA1126, combines durable construction with reliable performance. Featuring a blue raised button actuator, this switch is designed for panel mount installation and offers a contact rating of 5A. The switch is sealed and non-illuminated, perfect for use in various applications where IP6K4S protection is required. With a contact configuration of SPST-NO and gold-plated brass contacts, it ensures a high-quality electrical connection. The aluminum housing and thermoplastic actuator provide durability, with a 50,000 cycle lifespan. Operating at temperatures ranging from -55°C to 85°C and rated for 115VAC/28VDC, this switch offers versatility and reliability in demanding environments. Ideal for use in industries such as automotive, aerospace, and telecommunications, the P7AA1126 is a trusted solution for your switching needs.
