Han® Push-In Q 5/0, Q 7/0, Q 8/0
We are pleased to announce three new additional inserts for field termination. For size 3 A the new Han® Q 5/0 and Han® Q 7/0 inserts with push-in technology increase our portfolio, offering customers well known interfaces with yet another termination possibility. Additionally the Han® Q 8/0 insert with push-in termination is newly available. With the push-in inserts customers have the benefits of at termination that ensures robust and high-quality contacting. The Push-in termination technique is an advanced version of a standard cage-clamp for easy on-site connection. The focus here is on the fast and uncomplicated assembly of the connector with consistent quality and robustness.
Benefits
Features
Applications
Benefits
- Up to 30% less assembly time with direct insertion of the conductor into the contact chamber
- Easy handling due to tool-less termination
- Cost savings compared to alternative termination technologies
- Maximal flexibility – suitable for ferrules, stranded wires and solid conductors
- Compatible with identical products with other termination technologies
Features
- Han® Q Push-in for hoods and housings size Han® 3 A
- Q 5/0
- with 5 contacts +PE rated at 16 A 230/400 V 4 kV 3
- Conductor cross-section: 0.5 – 2.5 mm²
- Coding possibility: by 2 hexagonal coding pins
- Q 7/0
- with 7 contacts +PE rated at 10 A 400 V 6 kV 3
- Conductor cross section: 0.14 – 1.5 mm²
- Coding possibility: 6 way coding
- Q 5/0
- Han® Q 8/0 Push-in for hoods and housings size Han® Compact
- 8 contacts +PE rated at 16 A 500 V 6 kV 3
- Conductor cross-section: 0.5 – 2.5 mm²
- connection to metal hood/housing via PE plate
- new coding pin allowing 5 coding possibilities
- Mating compatible to existing Han® Q inserts
- Material flammability class V-0 acc. UL 94
Applications
- All industrial markets
- Machinery
- Robotics
- Infrastructure markets
- Energy
- Transportation
- Specific machinery applications
- Semiconductor production equipment
- Machine tools
- Injection moulding machines
