| Attribute | Value |
|---|---|
| Product Category: | |
| Manufacturer: | WAGO |
| Manufacturer Part Number: | WAGO 805-109 |
| Pitch: | 3.5 mm |
| Series: | 805 |
| Wire Size: | 24 to 16 AWG |
| Mount Type: | Through Hole |
| Housing Color: | Gray |
| Mounting Type: | Through Hole |
| Conductor Size: | 24 to 16 AWG |
| Current Rating: | 17.5 A |
| Voltage Rating: | 630 V |
| Contact Plating: | Tin |
| Number of Poles: | 9 |
| Contact Material: | Electrolytic Copper |
| Housing Material: | Nylon |
| Number of Levels: | 1 |
| Termination Method: | Push-In |
| Flammability Rating: | UL 94V-0 |
| Part Aliases: | 8050109 |
| SKU: | WAG805-109 |
805-109
| Heilind Number: | WAG805-109 |
| Manufacturer: | WAGO |
| Manufacturer Number: | 805-109 |
| ECAD Model: | |
Specifications
Detailed Description
The 805-109 is a high-quality PCB TRM STRIP 09-P.STAGGE connector, perfect for secure and efficient through-hole mounting. Its durable nylon housing and push-in termination method make it easy to install and maintain, while the electrolytic copper contacts with tin plating ensure reliable conductivity. With a pitch of 3.5mm and 9 poles in 1 level, this gray terminal block is suitable for a variety of applications. It is UL 94V-0 rated for safety and compliance, with a current rating of 17.5A and voltage rating of 630V. RoHS compliant and suitable for wire sizes 24-16 AWG, the 805-109 is a versatile and dependable choice for your connector needs.
Availability
In Stock:
Call
Stock Location:
In Stock
Factory Stock:
Call for Stock
Factory Lead:
Call
Unit Of Measure:
Each
Minimum/Multiple:
1/1
Invalid quantity value
Environmental & Export Classifications
| Attribute | Value |
|---|---|
| RoHS Compliant: | Unkown |
Additional Resources
| Attribute | Value |
|---|---|
| WAGO: | 805-109 |
| Other Names: | 8050109 |
